Opis
Dane techniczne:
- Woofer size 12″ (30 cm)
- Impedance 4 ohm
- Power handling capacity 250 W
- Max power handling capacity 500 W
- Peak power 750 W
- Frequency range 20 Hz – 2 kHz
- Sensitivity 91.2 dB
- Magnet size 120 mm (4.72″)
- Outer diameter of woofer 310 mm (12.12″)
- Mounting depth 133 mm (5.24″)
- Mounting hole 278 mm (10.94″)
- X-max +-9 mm
- Weight 4 kg ( 8.8 lb)
T/S parameters
- single V/C
- Fs 33 Hz
- Re 3.1 Ohm
- Qms 3.57
- Vas 113 liter
- Vas 4 Cuft
- Qes 0.48
- Qts 0.42
- Sd 491 cm²
- BL 9.58
