Opis
Dane techniczne:
- Woofer size 16.5 cm (6.5″)
- Tweeter T25. 25 mm (1.1″) silk dome tweeter
- Power handling capacity 100 W RMS / 200 W max
- Impedance 3 ohm
- Frequency range 30 – 20.000 Hz
- Sensitivity 86.7 dB (1W/1m)
- Crossover Filter box with 6/12 dB slope (LP/HP)
- Crossover point (Hz) 4500 Hz
- Size of filter box 145 x 85 x 45 mm ( 5.71 x 3.35 x 1.77″)
- Outer diameter of woofer 165 mm (6.5″)
- Magnet size 110 mm (4.33″)
- Mounting hole 140 mm (5.5″)
- Mounting depth 72 mm ( 2.83″)
T/S parameters
- Fs 51.8 Hz
- Re 2.7 Ohm
- Qms 3.85
- Vas 12.3 liter
- Vas 0.43 Cuft
- Qes 0.58
- Qts 0.51
- Sd 154 cm²
- BL 6.17
