Opis
Dane techniczne:
- Woofer size 10″ (25 cm)
- Impedance 4 ohm
- Power handling capacity 400 W RMS
- Max power handling capacity 600 W
- Peak power 800 W
- Frequency range 25 – 2000 Hz
- Sensitivity 87.2 dB (1W/1m)
- Magnet size 156 mm (6.14″) 50 oz
- Outer diameter of woofer 266 mm (10.47″)
- Mounting depth 125 mm (4.92″)
- Mounting hole 236 mm ( 9.29″)
- Weight 5.3 kg (11.68 lbs)
- X-max +- 9 mm (0.35″)
T/S parameters
- single V/C
- Fs 35.8 Hz
- Re 3.3 Ohm
- Qms 3.07
- Vas 38.5 liter
- Vas 1.36 Cuft
- Qes 0.36
- Qts 0.45
- Sd 366 cm²
- BL 11.5
